QYT KT-8900D 25W Dual band Quad Display 136-174&400-480MHz Large LCD Display Mobile Radio KT8900D
QYT KT-8900D 25W Dual band Quad Display 136-174&400-480MHz Large LCD Display Mobile Radio KT8900D
Couldn't load pickup availability
SPECIFICATIONS
Battery Capacity(mAh): depends on radio
Battery Included: no
Certification: CE
Dimensions: 98(W)*43(H)*126(D)mm
Frequency Range: VHF:136-174MHz UHF:400-480MHz
High-concerned chemical: None
Is_Display: Yes
Material: PLASTIC+Metal
Maximum Range: 10km-50km
Model Number: KT-8900D
Output Power(w): 10w-25w
Qyt Model: analog
Rechargeablebatteryincluded: No
Storage Channel: 200
Use: Motor vehicle
Walkie Talkie Type: Car
Waterproof / Water-Resistant: IP55
QYT KT-8900D 25W Dual band 136-174&400-480MHz Quad band Display Large LCD Display Mobile Radio KT8900D
Note: if you need the software, please contact us.
Dual band & Quad band Display!
New design & Upgraded version for QYT KT-8900 Dual Band Radio~
General specification
Frequency Range |
VHF:136-174MHz UHF： 400-480MHz |
Number of channels |
200 |
Channel spacing |
25KHz、 20K、12.5 |
Phase lock step step |
2.5KHz、5KHz、6.25 KHz、10 KHz、12.5 KHz、15 KHz、25 KHz |
Working voltage |
13.8V DC±15% |
Squelch way |
CTCSS、DCS、5Tone、2Tone、DTMF |
Frequency stability |
±2.6ppm |
Operat temperature |
-20+60℃ |
Dimension |
98(W)*43(H)*126(D)mm |
Weight |
448g |
Receive（ETSI EN 300 086 Standarddized.Test）
Broadband |
Narrow Band |
|
Sensitivity |
≤0.25μν |
≤0.35μν |
Channel Cholce |
≥70db |
≥60db |
Intermodulation |
≥65db |
≥60db |
Spurious Rejection |
≥70db |
≥70db |
Audio Response |
+1~~3db（0.3~3KHz） |
+1~~3db（0.3~2.55KHz） |
Signal to noise radio |
≥45db |
≥40db |
Audio Distortion |
≤5% |
|
Audio output power |
≥2W@10% |
|
Transmit（ETSI EN 300 086 Standarddized.Test）
Broadband |
Narrow Band |
|
Output Power |
25W/20W（VHF/UHF） |
|
Modulation Mode |
16KΦF3E |
11KΦF3E |
Channel Power |
≥70db |
≥60db |
Signal to noise radio |
≥40db |
≥36db |
Parasitic Harmonic |
≥60db |
≥60db |
Audio Response |
+1~~3db（0.3~3KHz） |
+1~~3db（0.3~2.55KHz） |
Audio Distortion |
≤5% |
|
